Ubiquiti UniFi Switch Aggregation (USW-Aggregation) is a managed Layer 2 switch with eight 10G SFP+ ports. Featuring a compact 4.7″ depth and fanless design, it supports high-bandwidth links to provide link aggregation for higher capacity and increased availability.

About this item

• Effectively increases available bandwidth on your network
• Built-in power supply to ensure all components are being supplied with accurate voltage
• Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
• Rack-mountable form factor for your convenience and simplicity of usage
• Management capability provides control over setup and configuration of your network
• Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
• Optical Fiber media support for efficient and reliable connectivity

Ubiquiti UniFi Switch Aggregation key features

• (8) 10G SFP+ Ports
• 160 Gbps switching capacity
• 1.3″ Touchscreen with AR switch management
• Fanless, 4.7″ depth compact enclosure
• 1U Rackmountable (kit included)
• Managed by UniFi Network Controller (version: 5.43.13 or higher)

Ubiquiti Switch Aggregation Technical Specification

Mechanical

• Dimensions: 442.4 x 120 x 43.7 mm (17.42 x 4.72 x 1.72″)
• Weight – Without Mount 2.65 kg (5.84 lb) – With Mount 2.74 kg (6.04 lb)
• Enclosure Material: SGCC Steel

Hardware

• Total Non-Blocking Throughput: 80 Gbps
• Switching Capacity: 160 Gbps
• Forwarding Rate: 119.04 Mpps
• Max. Power Consumption: 30W
• Power Method: Universal AC Input: 100-240VAC, 50/60 Hz
• Power Supply: AC/DC, Internal, 36W
• Management Interface: Ethernet In-Band
• Modes: SMB Layer 2 Gigabit Ethernet Switch
• ESD/EMP Protection: Air: ± 16kV, Contact: ± 12kV
• Operating Temperature: -5 to 40° C (23 to 104° F)
• Operating Humidity: 10 – 90% Noncondensing
• Certifications: CE, FCC, IC

LED

System

• (1) Bootup Animation: Bootup in Progress
• Firmware Upgrade Icon: Firmware Upgrading
• Steady White: Factory Defaults, Awaiting Adoption
• Steady Blue: Device is Adopted
• SFP+: White: 10G, 1G
