Ubiquiti USW-Pro-Max-48-PoE UniFi 48 port multi-gigabit PoE++ switch (USW-Pro-Max-48-PoE)

Ubiquiti Networks USW-PRO-MAX-48-POE Overview

Expand your business's network with the Pro Max 48 PoE 48-Port 2.5G / 1G Managed Network Switch from Ubiquiti Networks to support advanced IP cameras, access points, and other PoE compatible devices. Sixteen 2.5G Ethernet ports, comprised of eight 60W PoE++ ports and eight 30W ports, are available. Alongside them are eight Gigabit speed 60W Ethernet ports and 24 30W ports with a total power budget of 720W for compatible equipment. Four SFP+ ports are also available for up to 10 Gb/s uplinks.

Etherlighting technology illuminates each port to indicate the port location, speed/link status, and native VLAN/network configurations when used with compatible cables. A 1.3" touchscreen display provides important status information at a glance. Supporting a 224 Gb/s (112 Gb/s non-blocking) switching capacity and Layer 3 features, the Pro Max 48 PoE delivers smooth data transfers. Its settings may be managed through the UniFi Network platform.

Performance

This switch supports Layer 3 features with a 224 Gb/s (112 Gb/s non-blocking) switching capacity.

Backup Power

Connecting the DC backup power input to a compatible source provides failover support for added peace of mind.

A 48-port, Layer 3 Etherlighting™ switch with 2.5 GbE and PoE++ output.

Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network*

(16) 2.5 GbE ports including (8) PoE+ and (8) PoE++

(32) GbE ports including (24) PoE+ and (8) PoE++

(4) 10G SFP+ ports

DC power backup ready

720W total PoE availability

Managed with UniFi Network 8.0.24 and later
